ACE Industrial Shock Absorber adjustable
High energy absorption and progressive adjustment
- Code: ML6425EUM
- Description: High energy absorption and progressive adjustment
- Part no.: ML6425EUM
- Type: einstellbar
- Max. stroke: 25
- Stroke: 23.0
- a: 1
- d: 0
- Position Side Foot Mountig Kit: 0
- Angle: 0
- Attachment Parts: 1
- Length: 114.0, 174, 23.0, 260, 60
- Distance: 40, 75.5, 86
- Max. Energy Capacity: 1020
- Max. Energy Capacity Self-Contained: 124000
- Max. Energy Capacity with Air/Oil Tank: 248000
- Max. Energy Capacity with Oil Recirculation: 332000
- Effective Weight me: 300000, 7000
- Min. Return Force: 120, 155
- Rod Reset Time: 0.06
- Max. Side Load Angle: 5
- Weight: 2.5
- Product Specification: Datenblatt
Cad 3D
