ACE Miniature Shock Absorber self-compensating
Exceptionally high endurance and with the lowest resetting force
- Code: MC225EUMH3
- Description: Exceptionally high endurance and with the lowest resetting force
- Part no.: MC225EUMH3
- Max. Energy Capacity at continuous operation: 41
- Max. Energy Capacity at emergency stop: 45000
- Effective Weight me - Soft-Contact: 1814, 816
- Min. Return Force: 4, 9
- Rod Reset Time: 0.3
- Max. Side Load Angle: 4
- Weight: 0.15
- Max. stroke: 12.5
- Stroke: 0
- Attachment Parts: Standard
- Attachment parts on the outer tube: -
- Product Specification: Datenblatt
Cad 3D
