ACE Stacker Crane Shock Absorber
Industry design with high energy absorption
- Code: SCS33-25EU
- Description: Industry design with high energy absorption
- Max. stroke: 23.0
- Stroke: 23.00
- Accessories: NM (Locking Ring)
- Max length (A): 138
- Length: 83
- Distance Side Foot Mounting Kit: 0.00
- Max length (D): 68
- Max. Energy Capacity Self-Compensating: 310
- Max. Energy Capacity Optimised Version: 500
- Min. Return Force: 45
- Max. Return Force: 90
- Max. Side Load Angle: 3
- Weight: 0.45
