ACE Industrial Shock Absorber adjustable
High energy absorption and progressive adjustment
- Code: MA4525EUM
- Description: High energy absorption and progressive adjustment
- Part no.: MA4525EUM
- Type: einstellbar
- Max. stroke: 25
- Stroke: 23.0
- a: 1
- d: 0
- Position Side Foot Mountig Kit: 0
- Angle: 0
- Attachment Parts: 1
- Length: 145, 200, 23.0, 43, 95.0
- Distance: 32, 66, 66.0
- Max. Energy Capacity: 390
- Max. Energy Capacity Self-Contained: 107000
- Max. Energy Capacity with Air/Oil Tank: 158000
- Max. Energy Capacity with Oil Recirculation: 192000
- Effective Weight me: 10000, 40
- Min. Return Force: 100, 70
- Rod Reset Time: 0.03
- Max. Side Load Angle: 4
- Weight: 1.14
- Product Specification: Datenblatt
