ACE Miniature Shock Absorber adjustable
Stepless adjustment
- Code: MA35EUM
- Description: Stepless adjustment
- Part no.: MA35EUM
- Max. Energy Capacity at continuous operation: 4.0
- Max. Energy Capacity at emergency stop: 6000
- effective weight - adjusted: 57, 6
- Min. Return Force: 11, 5
- Rod Reset Time: 0.2
- Max. Side Load Angle: 2
- Weight: 0.043
- Max. stroke: 10.0
- Stroke: 0
- Attachment Parts: Standard
- Attachment parts on the outer tube: -
- Product Specification: Datenblatt
Cad 3D
