MSM-BS

Connecting clamps

Teknisk datablad
CE.74002-pa11_pa12

Velg deltype

Velg ønsket deltype for å se forhåndsvist tegning av tekniske dimensjoner

Bracket Material
Material
Bushing Material
Carrying Capacity
Diameter
Plunger Diameter
Type Of Assembly
Type Of Tube
Diameter Bases
Connecting Thread
External Diameter
Handle
Hole
Lever Length
Wheel Base
Threaded Screw
Hole Distance
Threaded Connection
Type Of Bellow
Type Of Vacuum Cups Holder
Vacuum Cup Holders Dimension
Vacuum Cups Dimension
Connector

Viser alle 8 resultater

    Vennligst velg en deltype for å få relevante valg.

    Lukk
    Code 500951
    Description MSM-BS-16-ANB
    d1
    —
    • —
    d2
    —
    • —
    d3
    —
    • —
    L
    —
    • —
    D
    —
    • —
    H
    —
    • —
    l1
    —
    • —
    b
    —
    • —
    h1
    —
    • —
    h2
    —
    • —
    h3
    —
    • —
    f
    —
    • —
    d3 Clamping kit
    —
    • —
    Weight
    —
    • —
    CAD
    Les mer
  • Code 500951
    Description MSM-BS-16-ANB
    d1 M4
    d2 4.5
    d3 8
    L 29
    D 31.5
    H 25
    l1 16
    b 8
    h1 17
    h2 7
    h3 3
    f 22
    d3 Clamping kit GN 511.1-M4-16
    Weight 18
    Les mer
  • Code 500956
    Description MSM-BS-16-MT
    d1 M4
    d2 4.5
    d3 7.5
    L 29
    D 31.5
    H 25
    l1 16
    b 8
    h1 17
    h2 7
    h3 3
    f 22
    d3 Clamping kit GN 511.1-M4-16
    Weight 18
    Les mer
  • Code 500961
    Description MSM-BS-20-ANB
    d1 M5
    d2 5.5
    d3 9
    L 35
    D 38
    H 30
    l1 20
    b 10
    h1 20
    h2 8
    h3 2.5
    f 27
    d3 Clamping kit GN 511.1-M5-20
    Weight 31
    Les mer
  • Code 500966
    Description MSM-BS-20-MT
    d1 M5
    d2 5.5
    d3 9
    L 35
    D 38
    H 30
    l1 20
    b 10
    h1 20
    h2 8
    h3 2.5
    f 27
    d3 Clamping kit GN 511.1-M5-20
    Weight 31
    Les mer
  • Code 500971
    Description MSM-BS-25-ANB
    d1 M6
    d2 6.5
    d3 10.5
    L 41
    D 45
    H 37
    l1 25
    b 12.5
    h1 24.5
    h2 10
    h3 4
    f 32
    d3 Clamping kit GN.511.1-M6-25
    Weight 55
    Les mer
  • Code 500976
    Description MSM-BS-25-MT
    d1 M6
    d2 6.5
    d3 10.5
    L 41
    D 45
    H 37
    l1 25
    b 12.5
    h1 24.5
    h2 10
    h3 4
    f 32
    d3 Clamping kit GN.511.1-M6-25
    Weight 55
    Les mer
  • Code 500981
    Description MSM-BS-30-ANB
    d1 M6
    d2 6.5
    d3 10.5
    L 44
    D 50
    H 44.5
    l1 30
    b 15
    h1 29.5
    h2 12.5
    h3 6.5
    f 36
    d3 Clamping kit GN 511.1-M6-30
    Weight 90
    Les mer
  • Code 500986
    Description MSM-BS-30-MT
    d1 M6
    d2 6.5
    d3 10.5
    L 44
    D 50
    H 44.5
    l1 30
    b 15
    h1 29.5
    h2 12.5
    h3 6.5
    f 36
    d3 Clamping kit GN 511.1-M6-30
    Weight 90
    Les mer
