MSM-Q

Connecting clamps

Teknisk datablad
CE.74032-pa11_pa12

Velg deltype

Velg ønsket deltype for å se forhåndsvist tegning av tekniske dimensjoner

Bracket Material
Material
Bushing Material
Carrying Capacity
Diameter
Plunger Diameter
Type Of Assembly
Type Of Tube
Diameter Bases
Connecting Thread
External Diameter
Handle
Hole
Lever Length
Wheel Base
Threaded Screw
Hole Distance
Threaded Connection
Type Of Bellow
Type Of Vacuum Cups Holder
Vacuum Cup Holders Dimension
Vacuum Cups Dimension
Connector

Viser alle 42 resultater

    Vennligst velg en deltype for å få relevante valg.

    Lukk
    Code 500451
    Description MSM-Q-S10-100-AL
    l
    —
    • —
    l1
    —
    • —
    s
    —
    • —
    s1
    —
    • —
    Weight
    —
    • —
    CAD
    Les mer
  • Code 500451
    Description MSM-Q-S10-100-AL
    l 100
    l1 15
    s 10
    s1 7
    Weight 11
    Les mer
  • Code 500453
    Description MSM-Q-S10-100-AL-CS
    l 100
    l1 15
    s 10
    s1 7
    Weight 11
    Les mer
  • Code 500455
    Description MSM-Q-S10-150-AL
    l 150
    l1 15
    s 10
    s1 7
    Weight 19
    Les mer
  • Code 500457
    Description MSM-Q-S10-150-AL-CS
    l 150
    l1 15
    s 10
    s1 7
    Weight 19
    Les mer
  • Code 500459
    Description MSM-Q-S10-200-AL
    l 200
    l1 15
    s 10
    s1 7
    Weight 25
    Les mer
  • Code 500461
    Description MSM-Q-S10-200-AL-CS
    l 200
    l1 15
    s 10
    s1 7
    Weight 25
    Les mer
  • Code 500463
    Description MSM-Q-S10-250-AL
    l 250
    l1 15
    s 10
    s1 7
    Weight 32
    Les mer
  • Code 500465
    Description MSM-Q-S10-250-AL-CS
    l 250
    l1 15
    s 10
    s1 7
    Weight 32
    Les mer
  • Code 500467
    Description MSM-Q-S10-300-AL
    l 300
    l1 15
    s 10
    s1 7
    Weight 38
    Les mer
  • Code 500469
    Description MSM-Q-S10-300-AL-CS
    l 300
    l1 15
    s 10
    s1 7
    Weight 38
    Les mer
  • Code 500885
    Description MSM-Q-S10-350-AL
    l 350
    l1 -
    s 10
    s1 7
    Weight 44
    Les mer
  • Code 500887
    Description MSM-Q-S10-350-AL-CS
    l 350
    l1 15
    s 10
    s1 7
    Weight 44
    Les mer
  • Code 500891
    Description MSM-Q-S10-400-AL
    l 400
    l1 -
    s 10
    s1 7
    Weight 51
    Les mer
  • Code 500893
    Description MSM-Q-S10-400-AL-CS
    l 400
    l1 15
    s 10
    s1 7
    Weight 51
    Les mer
  • Code 500471
    Description MSM-Q-S12-100-AL
    l 100
    l1 15
    s 12
    s1 9
    Weight 15
    Les mer
  • Code 500473
    Description MSM-Q-S12-100-AL-CS
    l 100
    l1 15
    s 12
    s1 9
    Weight 15
    Les mer
  • Code 500475
    Description MSM-Q-S12-150-AL
    l 150
    l1 15
    s 12
    s1 9
    Weight 23
    Les mer
  • Code 500477
    Description MSM-Q-S12-150-AL-CS
    l 150
    l1 15
    s 12
    s1 9
    Weight 23
    Les mer
  • Code 500479
    Description MSM-Q-S12-200-AL
    l 200
    l1 15
    s 12
    s1 9
    Weight 31
    Les mer
  • Code 500481
    Description MSM-Q-S12-200-AL-CS
    l 200
    l1 15
    s 12
    s1 9
    Weight 31
    Les mer
  • Code 500483
    Description MSM-Q-S12-250-AL
    l 250
    l1 15
    s 12
    s1 9
    Weight 39
    Les mer
  • Code 500485
    Description MSM-Q-S12-250-AL-CS
    l 250
    l1 15
    s 12
    s1 9
    Weight 39
    Les mer
  • Code 500487
    Description MSM-Q-S12-300-AL
    l 300
    l1 15
    s 12
    s1 9
    Weight 46
    Les mer
  • Code 500489
    Description MSM-Q-S12-300-AL-CS
    l 300
    l1 15
    s 12
    s1 9
    Weight 46
    Les mer
  • Code 500895
    Description MSM-Q-S12-350-AL
    l 350
    l1 -
    s 12
    s1 9
    Weight 54
    Les mer
  • Code 500897
    Description MSM-Q-S12-350-AL-CS
    l 350
    l1 15
    s 12
    s1 9
    Weight 54
    Les mer
  • Code 500901
    Description MSM-Q-S12-400-AL
    l 400
    l1 -
    s 12
    s1 9
    Weight 61
    Les mer
  • Code 500903
    Description MSM-Q-S12-400-AL-CS
    l 400
    l1 15
    s 12
    s1 9
    Weight 61
    Les mer
  • Code 500491
    Description MSM-Q-S16-100-AL
    l 100
    l1 20
    s 16
    s1 13
    Weight 21
    Les mer
  • Code 500493
    Description MSM-Q-S16-100-AL-CS
    l 100
    l1 20
    s 16
    s1 13
    Weight 21
    Les mer
  • Code 500495
    Description MSM-Q-S16-150-AL
    l 150
    l1 20
    s 16
    s1 13
    Weight 32
    Les mer
  • Code 500497
    Description MSM-Q-S16-150-AL-CS
    l 150
    l1 20
    s 16
    s1 13
    Weight 32
    Les mer
  • Code 500499
    Description MSM-Q-S16-200-AL
    l 200
    l1 20
    s 16
    s1 13
    Weight 43
    Les mer
  • Code 500501
    Description MSM-Q-S16-200-AL-CS
    l 200
    l1 20
    s 16
    s1 13
    Weight 43
    Les mer
  • Code 500503
    Description MSM-Q-S16-250-AL
    l 250
    l1 20
    s 16
    s1 13
    Weight 53
    Les mer
  • Code 500505
    Description MSM-Q-S16-250-AL-CS
    l 250
    l1 20
    s 16
    s1 13
    Weight 53
    Les mer
  • Code 500507
    Description MSM-Q-S16-300-AL
    l 300
    l1 20
    s 16
    s1 13
    Weight 64
    Les mer
  • Code 500509
    Description MSM-Q-S16-300-AL-CS
    l 300
    l1 20
    s 16
    s1 13
    Weight 64
    Les mer
  • Code 500905
    Description MSM-Q-S16-350-AL
    l 350
    l1 -
    s 16
    s1 13
    Weight 74
    Les mer
  • Code 500907
    Description MSM-Q-S16-350-AL-CS
    l 350
    l1 20
    s 16
    s1 13
    Weight 74
    Les mer
  • Code 500911
    Description MSM-Q-S16-400-AL
    l 400
    l1 -
    s 16
    s1 13
    Weight 85
    Les mer
  • Code 500913
    Description MSM-Q-S16-400-AL-CS
    l 400
    l1 20
    s 16
    s1 13
    Weight 85
    Les mer
