LS.VA-32-14-STP-M8X69
LS.VA-32-14-STP-M8x69
- Code: 342128
- Description: LS.VA-32-14-STP-M8x69
- Rotation: 0
- D: 32
- d: M8
- d1: 23.1
- l: 69
- l1: 26
- l2: 5.3
- l3: 5
- h: 17
- s: 16
- s1: 3
- a: 14
- l2 0: 5.3
- l2 0.4: 4.8
- l2 0.6: 4.6
- Area damping insert: 239
- Max limit static load: 96
- Weight: 21.5
